1. Excavation

Excavation will be done up to the hard strata (yellow soil) & maximum depth will be 8 feet. Extra work rates will be charged as per cpwd norms.

2. Backfilling

50 % backfilling will be done by existing soil. 50 % backfilling will be done by morrum.

3. Plinth Height

Plinth height will be 1'6" from the ground level.

4. Steel Reinforcement

ISI mark FE-500, Moira or equivalent

5. Concrete

PCC-M7.5, Footing-M20, Plinth Slab-M10, Floor Slab-M20, Column-M20.

6. General Civil Items

For Super Structure- Sand (nemawar ,hoshangabad). For Sub Structure- M sand, Cement – birla A1, Aggregate-as per local availibility(15-20mm), Fly ash brick, outer wall 4”, inner wall 4”.

7. Slab Height

10 feet (top of slab to top of slab next floor)

8. UGT

Under Ground Tank within construction slab area 5000 ltrs with 4" Brick, 4" RCC

1. Plumbing & Sanitary Concealed Material

SWR pipe-kisan (4kg), SWR pipe 6"-for main drainage line, SWR pipe 4"-for branch /connecting line, RWP-3 inche pipe, CPVC pipe-finolex/ vectus, Main line-1 inche, Internal line toilet line-0.75 inche.

2. Overhead Water Tank

Capacity-1000 LTR Brand- VECTUS Layers-3 Layer

1. Fabrication Work

200 kg per 1000 sq feet construction area

2. Staircase Railing

Railing type- S.S. Railing with round hand rail. Railing quantity-max. 25 rft. Per floor

3. Window

Window- Type of track-3 track(all) , Gauge-20, Mosquito net- aluminiumn, Glass thickness-4mm (colour-only black) , Ventilation- ms fix type.

4. Painting

Internal colour- Batti ghisai, 2 coat putty birla white, 1 coat water based primer, 1 coat acrylic putty, 2 coat colour. Brand – Asian , Exterior colour- 1 coat primer , 2 coat paint, Brand- Asian. Rate of color mentioned in annexure iii

5. Door Work

Main door- Rate-22000, (for door -16000, For frame-5000, For acce.-1000). Room doors - Rate-10500, (for door -5500, For frame-4000, For acce.-1000), Terrace, wash area - Rate-6000, (for door -3000, For frame-2500, For acce.-500). Toilet-2 nos Rate-6000 (for door with frame and accessories -6000), No. Of doors as per mentioned in notes as per construction area.

6. Electrical

Wiring: All Cable Size as required of Polycab. Switches/ Sockets/ MCB: All Switches/ Sockets & MCB as required of anchor/ Havells or Equivalent Brand.

7. Flooring & Granite

For floor tiles including skirting Rs. 50 per Sq. Ft., Bathroom Tiles Rs. 35 per Sq. Ft., Parking Tiles Rs. 32 per Sq. Ft, Granite – Rs. 110 per Sq.

1. Excavation

Excavation will be done up to the hard strata (yellow soil) & maximum depth will be 8 feet. Extra work rates will be charged as per cpwd norms.

2. Backfilling

50 % backfilling will be done by existing soil. 50 % backfilling will be done by morrum.

3. Plinth Height

Plinth height will be 2' from the ground level.

4. Steel Reinforcement

ISI mark FE-500, Moira or equivalent

5. Concrete

PCC-M7.5, Footing-M20, Plinth Slab-M10, Floor Slab-M20, Column-M20.

6. General Civil Items

For Super Structure- Sand (nemawar ,hoshangabad) Red brick For sub structure M sand Fly ash brick Cement – birla a1 Aggregate-as per local availibility(15-20mm) Outer wall 8”, inner wall 4”

7. Slab Height

11 feet (top of slab to top of slab next floor)

8. UGT

Under Ground Tank within construction slab area 5000 ltrs with 4" Brick, 4" RCC

1. Plumbing & Sanitary Concealed Material

SWR pipe-kisan (4kg) SWR pipe 6"-for main drainage line, SWR pipe 4"-for branch /connecting line, RWP-3 inche pipe, CPVC pipe-finolex/ vectus, Main line-1 inche, Internal line toilet line-0.75 inche.

2. Overhead Water Tank

Capacity-1500 LTR Brand- VECTUS Layers-6 Layer

1. Fabrication Work

200 kg per 1000 sq feet construction area

2. Staircase Railing

Railing type- S.S. Railing with round hand rail. Railing quantity-max. 25 rft. Per floor

3. Window

Window- Type of track-3 track(all) Gauge-20 Mosquito net- aluminiumn Glass thickness-4mm (colour-only black) Ventilation- ms fix type

4. Painting

Internal colour- Batti ghisai, 2 coat putty birla white, 1 coat water based primer, 2 coat acrylic putty, 2 coat colour. Brand – Asian Exterior colour- 1 coat primer , 2 coat paint, Brand- Asian. Rate of color mentioned in annexure iii.

5. Door Work

Main door- Rate-25000 (for door -18000 For frame-5000 For acce.-1000) Room doors - Rate-12000 (for door -12000 For frame-4000 For acce.-1000) Terrace, wash area Rate-6000 (for door -3000 For frame-2500 For acce.-500) Toilet-2 nos Rate-7500 (for door with frame and accessories -7500) No. Of doors as per mentioned in notes as per construction area.

6. Electrical

Wiring: All Cable Size as required of Polycab. Switches/ Sockets/ MCB: All Switches/ Sockets & MCB as required of anchor/ Havells or Equivalent Brand.

7. Flooring & Granite

For floor tiles including skirting Rs. 75 per Sq. Ft., Bathroom Tiles Rs. 50 per Sq. Ft., Parking Tiles Rs. 40 per Sq. Ft, Granite – Rs. 175 per Sq. ft.

1. Excavation

Excavation will be done up to the hard strata (yellow soil) & maximum depth will be 8 feet. Extra work rates will be charged as per cpwd norms.

2. Backfilling

25 % backfilling will be done by existing soil. 75 % backfilling will be done by morrum.

3. Plinth Height

Plinth height will be 2'6" from the ground level.

4. Steel Reinforcement

ISI mark FE-500, Moira or equivalent

5. Concrete

PCC-M7.5, Footing-M25, Plinth Slab-M10, Floor Slab-M25, Column-M25.

6. General Civil Items

For Super Structure- Sand (nemawar ,hoshangabad) Red brick. For Sub Structure - M sand Fly ash brick, Cement – birla a1, Aggregate-as per local availibility(15-20mm), Outer wall 8”, inner wall 4”

7. Slab Height

11’6” (top of slab to top of slab next floor)

8. UGT

Under Ground Tank within construction slab area 8000 ltrs with 4" Brick, 4" RCC

1. Plumbing & Sanitary Concealed Material

SWR pipe-kisan (4kg) SWR pipe 6"-for main drainage line SWR pipe 4"-for branch /connecting line. RWP-3 inche pipe, CPVC pipe-finolex/ vectus, Main line-1 inche, Internal line toilet line-0.75 inche.

2. Overhead Water Tank

Capacity-1500 LTR Brand- VECTUS. Layers-6 Layer.

1. Fabrication Work

200 kg per 1000 sq feet construction area

2. Staircase Railing

Railing type- S.S. Railing with round hand rail. Railing quantity-max. 50 rft. Per floor

3. Window

Window- Type of track-3 track(all), Gauge-16, Mosquito net- aluminiumn, Glass thickness-4mm (colour-only black) , Ventilation- ms fix type , Rates Mentioned in Annexure III ,

4. Painting

Internal colour- Batti ghisai, 2 coat putty birla white, 1 coat water based primer, 2 coat acrylic putty, 2 coat colour. Brand – Asian Exterior colour- 2 coat primer , 2 coat paint, Brand- Asian. Rate of color mentioned in annexure iii.

5. Door Work

Main door- Rate-35000 (for door -23000 For frame-8000 For acce.-4000) Room doors - Rate-14000 (for door -7500 For frame-5000 For acce.-2500) Terrace, wash area Rate-6000 (for door -3000 For frame-2500 For acce.-500) Toilet-2 nos Rate- 10000 (for door with frame and accessories -1000) No. Of doors as per mentioned in notes as per construction area.

6. Electrical

Wiring: All Cable Size as required of Polycab. Switches/ Sockets/ MCB: All Switches/ Sockets & MCB as required of anchor/ Havells or Equivalent Brand.

7. Flooring & Granite

For floor tiles including skirting Rs. 100 per Sq. Ft., Bathroom Tiles Rs. 60 per Sq. Ft., Parking Tiles Rs. 40 per Sq. Ft, Granite – Rs. 250 per Sq. ft.
